Setting Up Intelligent Bot Detection

This tutorial guides you through configuring Peakhour's intelligent bot detection system to protect your website from malicious automation while allowing legitimate crawlers. By the end, you'll have a comprehensive bot protection strategy that distinguishes between good bots and threats.

Duration: 30 minutes
Prerequisites: Active Peakhour domain, basic understanding of web traffic patterns
Learning Goals: Configure JavaScript challenges, verify legitimate bots, set up challenge-based rate limiting, monitor bot activity

What You'll Build: A complete bot detection system that challenges suspicious automation, verifies legitimate crawlers, and provides detailed analytics on bot activity across your site.

Understanding Bot Detection Methods

Peakhour uses a multi-layered approach to identify and manage automated traffic:

Detection Layers

• Network Fingerprinting: Identifies clients by analyzing their unique TLS, HTTP/2, and TCP signatures. This is highly effective at detecting automated tools that have consistent network-level behavior.
• JavaScript Challenges: Browser validation to detect headless automation.
• User Agent Verification: Legitimate crawler identification with reverse DNS confirmation.
• Challenge Cookies: Fingerprint-based tracking using IP, session, and network signatures.
• Rate Limiting Integration: Challenge escalation for suspicious traffic patterns.
• IP Reputation: Integration with threat intelligence blocklists for known bad bots.

Bot Classifications

• Simple Bots: Automation that fails basic verification checks
• Advanced Bots: Sophisticated automation that bypasses initial detection but fails JavaScript challenges
• Legitimate Crawlers: Verified search engines, social media, and service bots
• Malicious Bots: Scrapers, attackers, and unauthorized automation

Enable Basic Bot Protection

Access Bot Settings

1. Navigate to your Peakhour dashboard
2. Select your domain from the domain list
3. Go to Security > Bot Protection
4. Review current bot protection status

Configure JavaScript Injection

Enable lightweight JavaScript challenges:

1. Enable Bot Detection: Check "Inject lightweight JavaScript into the browser to assist with Bot detection"
2. Review Impact: This adds minimal JavaScript (< 2KB) to pages for browser validation
3. Test Compatibility: Verify with your site's existing JavaScript frameworks

Expected Behavior: Legitimate browsers execute JavaScript and receive access tokens, while headless automation tools fail the challenge.

Initial Configuration Review

Your basic setup should show:

✅ JavaScript Injection: Enabled
✅ Challenge System: Active
✅ Analytics Tracking: Configured

Configure Legitimate Bot Access

Select Verified Bots

Choose which legitimate bots to allow through verification:

1. Navigate to Bot Verification List
2. Select trusted crawlers:
3. Google: Search indexing and services
4. Bing: Microsoft search engine
5. Yandex: Russian search engine
6. Facebook: Social media crawling
7. Apple: Siri and search features
8. Pinterest: Content discovery
9. Stripe: Payment processing verification
10. LetsEncrypt: Certificate validation

Best Practice: Start with essential services (Google, Bing) and add others based on your site's needs.

Enable Reverse DNS Verification

Protect against bot impersonation:

1. Enable rDNS Verification: Check "Verify bots against published IP ranges using reverse DNS"
2. How it Works: Bots claiming to be from Google must originate from Google's published IP ranges
3. Block Impersonators: Fake crawlers using search engine user agents are blocked

Security Benefit: Prevents malicious bots from bypassing protection by spoofing legitimate user agents.

Test Legitimate Bot Access

Verify your configuration doesn't block wanted crawlers:

1. Check Search Console for crawl errors after 24 hours
2. Monitor Social Media tools for access issues
3. Review Service Integrations (payments, monitoring) for failures

Configure Advanced Challenge System

Set Challenge Cookie Keys

Configure fingerprinting elements for challenge tracking:

1. Navigate to Firewall > Challenge Configuration
2. Select challenge key components:
3. IP Address: Track challenges per IP
4. Session ID: Per-session challenge tracking
5. TLS Fingerprint: Device/client fingerprinting

Recommended Setup:

☑ IP Address (essential for distributed attacks)
☑ TLS Fingerprint (device identification)
☐ Session ID (for session-specific tracking)

Challenge Duration and Behavior

Configure challenge persistence:

1. Challenge Validity: Set how long successful challenges remain valid
2. Challenge Difficulty: Balance security vs. user experience
3. Retry Logic: Configure failed challenge handling

Example Configuration:

Challenge Duration: 24 hours
Retry Attempts: 3 failures before temporary block
Grace Period: 5 minutes between challenge attempts

Integrate with Rate Limiting

Create Challenge-Based Rate Limits

Set up rate limiting that escalates to challenges rather than immediate blocks:

1. Navigate to Rules > Rate Limiting
2. Create a new rate limit rule:

   Name: "Suspicious Activity Challenge"
   Pattern: All requests to sensitive paths
   Threshold: 100 requests per minute
   Action: CHALLENGE (not BLOCK)


Configure Path-Specific Protection

Protect high-value endpoints:

1. Login Pages:

   Path: /login, /signin
   Rate: 20 requests per 5 minutes
   Action: Challenge after threshold


2. API Endpoints:

   Path: /api/*
   Rate: 500 requests per hour
   Action: Challenge suspicious patterns


3. Search/Browse Pages:

   Path: /search, /category/*
   Rate: 200 requests per 10 minutes
   Action: Challenge after threshold


Test Rate Limit Integration

Verify challenge escalation works correctly:

1. Trigger Rate Limit: Make requests above threshold from test IP
2. Verify Challenge: Confirm JavaScript challenge appears instead of block
3. Complete Challenge: Ensure successful completion grants access
4. Monitor Analytics: Check challenge events in dashboard

Configure Firewall Integration

Create Firewall Challenge Rules

Use firewall rules to trigger challenges for suspicious patterns:

1. Navigate to Rules > Firewall
2. Create challenge rules for suspicious behavior:

Example Rules:

1. Suspicious User Agents:

   Name: Challenge Suspicious User Agents
   Expression: http.user_agent matches ".*(curl|wget|python|scanner).*"
   Action: CHALLENGE


2. Missing Headers:

   Name: Challenge Headless Browsers
   Expression: not http.accept exists or http.accept eq ""
   Action: CHALLENGE


3. Suspicious Network Fingerprints:

   Name: Challenge Suspicious TLS Fingerprints
   Expression: fingerprint.tls in $suspicious_tls_fingerprints
   Action: CHALLENGE


   Note: You will need to create a text list named suspicious_tls_fingerprints containing fingerprints of known bots or malicious tools. For more information, see the Network Fingerprinting guide.

4. High-Risk Countries:

   Name: Challenge High-Risk Locations
   Expression: ip.geoip.country in {"CN", "RU", "BR"}
   Action: CHALLENGE


Geographic Challenge Rules

Implement location-based challenges:

Name: Challenge International Traffic
Expression: ip.geoip.country ne "US" and
           not ip.geoip.country in {"CA", "GB", "AU"}
Action: CHALLENGE
Priority: 10

This challenges international traffic while allowing major English-speaking countries.

Monitor and Analyze Bot Activity

Review Bot Analytics Dashboard

Access comprehensive bot activity metrics:

1. Navigate to Analytics > Bot Detection
2. Review key metrics:
3. Challenge Success Rate: Percentage of challenges completed successfully
4. Bot Classification: Simple vs. Advanced bot detection breakdown
5. Geographic Distribution: Bot activity by country/region
6. Temporal Patterns: Bot activity over time

Investigate Bot Events

Analyze specific bot encounters:

1. Go to Security > Bot Events
2. Review recent events with details:
3. IP Address and Location
4. User Agent String
5. Detection Method (Simple/Advanced)
6. Challenge Outcome
7. Request Pattern

Analyze Traffic Patterns

Look for patterns indicating bot activity:

Indicators of Bot Traffic:

• High request rates from single IPs
• Unusual user agent strings
• Missing or unusual request headers
• Geographic clustering of requests
• Failed JavaScript challenges

Example Investigation:

Event: Advanced Bot Detection
IP: 203.0.113.42
Location: United States (Automated Detection)
User Agent: Mozilla/5.0... (suspicious)
Pattern: 500 requests in 60 seconds
Outcome: JavaScript challenge failed

Optimize Bot Protection

Review Challenge Success Rates

Analyze challenge effectiveness:

1. High Success Rate (>80%): Challenges may be too easy
2. Low Success Rate (<40%): Challenges may be too difficult or affecting legitimate users
3. Optimal Range (60-80%): Good balance of security and usability

Adjust Based on Analytics

Fine-tune settings based on observed patterns:

Common Optimizations:

1. Reduce False Positives:

   Issue: Legitimate users failing challenges
   Solution: Reduce challenge difficulty or add user agent exceptions


2. Increase Bot Detection:

   Issue: Sophisticated bots bypassing detection
   Solution: Enable additional challenge keys (TLS fingerprint)


3. Geographic Adjustments:

   Issue: Legitimate international traffic challenged
   Solution: Refine geographic rules or add allow-list


Integrate with IP Reputation

Leverage threat intelligence for enhanced protection:

1. Review Blocked Sources: Analyze automatically blocked IP reputation sources
2. Custom Blocklists: Add specific IP ranges based on observed attack patterns
3. Allow Lists: Create exceptions for legitimate high-traffic sources

Example Custom Rule:

Name: Allow Verified Partners
Expression: ip.src in {203.0.113.0/24, 198.51.100.0/24}
Action: ALLOW
Priority: 1

Establish Monitoring and Maintenance

Set Up Alerts

Configure notifications for unusual bot activity:

1. Challenge Spike Alert: Unusual increase in challenge attempts
2. Geographic Anomaly: Bot activity from new geographic regions
3. Success Rate Drop: Significant change in challenge completion rates
4. Volume Threshold: Bot traffic exceeding normal baselines

Regular Review Schedule

Establish ongoing maintenance:

Weekly Reviews:

• Bot event summary and trends
• Challenge success rate analysis
• False positive identification

Monthly Reviews:

• Bot verification list updates
• Geographic rule adjustments
• Rate limiting threshold optimization

Quarterly Reviews:

• Overall bot protection strategy
• Integration with new services
• Challenge system effectiveness assessment

Emergency Procedures

Prepare for bot attack scenarios:

High-Volume Attack Response:

1. Temporarily lower rate limiting thresholds
2. Enable stricter challenge requirements
3. Implement emergency IP blocking
4. Monitor legitimate user impact

Challenge System Issues:

1. Temporary disable JavaScript injection if affecting users
2. Switch to basic user agent verification
3. Implement manual allow-lists for critical traffic

Troubleshooting Common Issues

Challenge Loop Problems

Problem: Users get stuck in repeated challenges Solution: - Check challenge cookie configuration - Verify JavaScript compatibility with your site - Review session management settings

Legitimate Crawlers Blocked

Problem: Search engines can't crawl your site Solution:

• Verify reverse DNS is enabled
• Add missing crawlers to verification list
• Check firewall rules aren't overriding bot settings

High False Positive Rate

Problem: Real users frequently challenged
Solution:

• Reduce challenge sensitivity
• Add user agent exceptions for legitimate tools
• Review geographic rules for broad restrictions

Next Steps

With your bot detection system operational:

1. Expand Coverage: Apply similar protection to additional domains
2. API Protection: Implement service-specific bot rules for APIs
3. Advanced Analytics: Set up custom dashboards for bot monitoring
4. Integration: Connect bot events with SIEM systems for comprehensive security

Key Concepts Learned

• Multi-Layer Detection: JavaScript challenges, user agent verification, and fingerprinting work together
• Challenge-Based Protection: Escalation from logging to challenges to blocking based on threat level
• Legitimate Bot Management: Proper verification ensures search engines and services maintain access
• Analytics-Driven Optimization: Regular monitoring and adjustment improves effectiveness while reducing false positives

You've successfully implemented a sophisticated bot detection system that protects against automated threats while maintaining accessibility for legitimate crawlers and users. This foundation can be extended with additional rules and integrations as your security requirements evolve.
