Protecting APIs with Peakhour Security¶

This guide shows you how to implement comprehensive API security using Peakhour's advanced features including WAF rules, rate limiting, schema validation, and endpoint discovery to protect your API infrastructure.

Before you begin: Understand WAF concepts and API security fundamentals.

API Security Overview¶

Modern API security requires multiple layers of protection. Peakhour provides comprehensive API security through:

Endpoint Discovery: Automatic detection and cataloging of API endpoints
Schema Validation: Ensure requests match expected API schemas
Rate Limiting: Protect against abuse and DDoS attacks
WAF Protection: Block injection attacks and malicious payloads
Access Control: Authenticate and authorize API consumers

Enable API Discovery¶

Access API Discovery Settings¶

Log into Peakhour Dashboard
Select Your Domain from the domain list
Navigate to Security → API Discovery
Click Enable API Discovery for your domain

Configure Discovery Parameters¶

Basic Discovery Settings:

Auto-Discovery: Enable automatic endpoint detection
Learning Period: Set initial observation period (7-30 days recommended)
Traffic Threshold: Minimum requests needed to catalog an endpoint
Content-Type Detection: Automatically identify API vs web traffic

Advanced Options:

Parameter Learning: Extract and catalog API parameters
Schema Generation: Build OpenAPI specifications from traffic
Version Detection: Identify different API versions
Response Code Analysis: Track success/error patterns

Review Discovered Endpoints¶

After the learning period, review discovered API endpoints:

Navigate to API Discovery → Endpoints

Review Endpoint List:

GET  /api/v1/users          [Discovered: 2024-01-15]
POST /api/v1/users          [Discovered: 2024-01-15]
GET  /api/v1/users/{id}     [Discovered: 2024-01-16]
PUT  /api/v1/users/{id}     [Discovered: 2024-01-16]

Examine Endpoint Details:
Request Parameters: Query, path, and body parameters
Response Codes: HTTP status codes observed
Traffic Volume: Request frequency and patterns
Security Events: Any attacks or anomalies detected

Create API-Specific Security Rules¶

Protect API Authentication Endpoints¶

Scenario: Secure login and token endpoints from brute force attacks

Navigate to Rules → Firewall

Create New Rule:

Name: API Authentication Protection
Expression: (http.request.uri.path eq "/api/v1/auth/login" or
           http.request.uri.path eq "/api/v1/auth/token") and
           rate(5m) > 10
Action: challenge
Description: Rate limit authentication attempts

Block SQL Injection in API Parameters¶

Scenario: Protect API endpoints from SQL injection attacks

Name: API SQL Injection Protection
Expression: starts_with(http.request.uri.path, "/api/") and
           (any(http.request.uri.args.values[*] matches ".*(?i)(union|select|insert|drop|delete|exec|script).*") or
            any(http.request.body.form.values[*] matches ".*(?i)(union|select|insert|drop|delete|exec|script).*"))
Action: deny
Description: Block SQL injection attempts in API requests

Implement API Rate Limiting¶

Create Tiered Rate Limits¶

Free Tier API Limiting:

Name: Free Tier API Limits
Expression: starts_with(http.request.uri.path, "/api/") and
           not (http.request.headers["x-api-tier"] eq "premium")
Action: rate_limit
Rate: 100 requests per hour per IP
Burst: 10 requests

Premium Tier API Limiting:

Name: Premium Tier API Limits
Expression: starts_with(http.request.uri.path, "/api/") and
           http.request.headers["x-api-tier"] eq "premium"
Action: rate_limit
Rate: 1000 requests per hour per API key
Burst: 50 requests

Endpoint-Specific Rate Limits¶

High-Cost Operations:

Name: Expensive API Operations
Expression: http.request.uri.path in {"/api/v1/reports/generate",
                                    "/api/v1/export/data",
                                    "/api/v1/ai/process"}
Action: rate_limit
Rate: 5 requests per minute per API key
Description: Limit resource-intensive operations

Search and Query Endpoints:

Name: API Search Rate Limiting
Expression: starts_with(http.request.uri.path, "/api/v1/search") or
           contains(http.request.uri.path, "/query")
Action: rate_limit
Rate: 60 requests per minute per IP
Burst: 10 requests

API Authentication and Authorization¶

API Key Validation Rules¶

Require API Keys for Protected Endpoints:

Name: API Key Required
Expression: starts_with(http.request.uri.path, "/api/v1/") and
           not starts_with(http.request.uri.path, "/api/v1/public/") and
           len(http.request.headers["x-api-key"]) == 0
Action: deny
Response Code: 401
Custom Response: {"error": "API key required", "code": "MISSING_API_KEY"}

Bearer Token Protection¶

Advanced API Protection¶

GraphQL Query Complexity Protection¶

Block Introspection in Production:

Name: Block GraphQL Introspection
Expression: http.request.uri.path eq "/graphql" and
           contains(lower(http.request.body.json.query), "__schema")
Action: deny
Description: Prevent GraphQL schema introspection

API Version and Deprecation Management¶

Redirect Deprecated API Versions:

Name: Deprecated API Version Redirect
Expression: starts_with(http.request.uri.path, "/api/v1/") and
           http.request.uri.path in $deprecated_endpoints
Action: redirect
Status Code: 301
Location: Rewrite path to /api/v2/

API Monitoring and Analytics¶

Set Up API Performance Monitoring¶

Navigate to Analytics → API Performance
Configure Monitoring:
Response Time Tracking: Monitor API latency
Error Rate Monitoring: Track 4xx and 5xx responses
Throughput Analysis: Requests per second by endpoint
User Behavior: API usage patterns by consumer

Security Event Monitoring¶

Monitor for API Attacks:

Injection Attempts: SQL, NoSQL, command injection
Authentication Attacks: Brute force, credential stuffing
Rate Limit Violations: Abuse detection
Data Exfiltration: Unusual download patterns

Set Up Alerts:

Alert Conditions:

- Error rate > 5% for any endpoint
- Authentication failures > 50 per minute
- Rate limit violations > 100 per hour
- New endpoints discovered without approval

API Documentation and Schema Management¶

Generate OpenAPI Documentation¶

Navigate to API Discovery → Schema Export
Generate OpenAPI Spec:
Version: Choose OpenAPI 3.0 or 3.1
Scope: Select endpoints to include
Detail Level: Include parameters, responses, examples
Security Schemes: Document authentication methods

Review Generated Schema:

openapi: 3.0.3
info:
  title: Your API
  version: 1.0.0
paths:
  /api/v1/users:
    get:
      parameters:
        - name: limit
          in: query
          schema:
            type: integer
            minimum: 1
            maximum: 100

Schema Validation Rules¶

API Security Best Practices¶

Content Security Policies¶

API Content-Type Enforcement:

Name: API Content-Type Validation
Expression: starts_with(http.request.uri.path, "/api/") and
           http.request.method in {"POST", "PUT", "PATCH"} and
           http.content_type not in {"application/json", "application/xml"}
Action: deny
Response Code: 415
Description: Enforce supported content types

Configure CORS for API Endpoints:

Name: API CORS Configuration
Expression: starts_with(http.request.uri.path, "/api/") and
           http.request.method eq "OPTIONS"
Action: allow
Response Headers:
  Access-Control-Allow-Origin: https://app.yourdomain.com
  Access-Control-Allow-Methods: GET, POST, PUT, DELETE
  Access-Control-Allow-Headers: Content-Type, Authorization, X-API-Key

Security Headers for APIs¶

Add Security Headers to API Responses:

Name: API Security Headers
Expression: starts_with(http.request.uri.path, "/api/")
Action: allow
Response Headers:
  X-Content-Type-Options: nosniff
  X-Frame-Options: DENY
  X-XSS-Protection: "1; mode=block"
  Strict-Transport-Security: max-age=31536000; includeSubDomains

Troubleshooting API Security¶

Common Issues¶

High False Positive Rates:

Review and tune rule sensitivity
Add legitimate traffic to allowlists
Implement graduated response (log → challenge → block)
Monitor API consumer feedback

Performance Impact:

Optimize rule evaluation order
Use caching for schema validation
Implement rule bypass for trusted sources
Monitor API response times

Schema Drift:

Set up automated schema updates
Version control API schemas
Implement backward compatibility checks
Alert on schema changes

Monitoring and Optimization¶

Regular Review Tasks:

Weekly API security rule effectiveness review
Monthly false positive analysis
Quarterly API consumer behavior analysis
Semi-annual security architecture review

Performance Optimization:

Profile rule execution times
Optimize complex regular expressions
Cache frequently accessed schemas
Use edge computing for validation

This comprehensive API security implementation provides robust protection while maintaining performance and usability for legitimate API consumers.
